How to Install Apache Flink on Ubuntu 26.04 LTS (2026)

July 27, 2026

Apache Flink is a distributed stream- and batch-processing engine used for real-time analytics, event-driven applications, and large-scale data pipelines. This guide walks through installing Apache Flink 2.3.0 — the current stable release — on Ubuntu 26.04 LTS, covering both a standalone single-node setup for development and a standalone cluster layout for production-style testing.

By the end of this tutorial you’ll have a running Flink JobManager and TaskManager, access to the Flink Web UI, and a submitted example job proving the cluster works end to end.

Prerequisites
Installation Methods Compared
Architecture: How Flink Processes Data
Method 1: Standalone Installation from Binary Archive (Recommended)
Method 2: Running Flink with Docker
Configuring Flink
Starting the Cluster
Accessing the Flink Web UI
Submitting Your First Flink Job
Setting Up a Multi-Node Standalone Cluster
Running Flink as a systemd Service
Troubleshooting
Uninstalling Flink
FAQ
Related Reads on bckinfo.com

Prerequisites

Before installing Flink, make sure your Ubuntu 26.04 LTS system meets the following requirements:

A user account with sudo privileges
An active internet connection
JDK 17 or JDK 21 — Flink 2.x dropped support for Java 8 and Java 11, so a modern LTS JDK is mandatory
At least 2 GB of free RAM for a minimal local setup (production clusters need considerably more, depending on job parallelism)
A dedicated, non-root system user for running Flink is recommended for production installs

Step 1 — Install OpenJDK 21

sudo apt update
sudo apt install -y openjdk-21-jdk

Verify the installation:

java -version

Expected output:

openjdk version "21.0.x" 2026-xx-xx
OpenJDK Runtime Environment (build 21.0.x+xx-Ubuntu-x)
OpenJDK 64-Bit Server VM (build 21.0.x+xx-Ubuntu-x, mixed mode, sharing)

Step 2 — Install supporting utilities

sudo apt install -y wget tar

Installation Methods Compared

Method	Best For	Version Freshness	Cluster-Ready	Root Required
Standalone Binary	Development, learning, bare-metal/VM clusters	Pinned to whatever archive you download	Yes, with manual `masters`/`workers` config	No (can run under an unprivileged user)
Docker	Quick local testing, CI pipelines, ephemeral environments	Whatever tag you pull	Yes, via Docker Compose	Depends on Docker setup
Kubernetes Operator	Production clusters already on Kubernetes	Latest, via Helm/operator versioning	Native	No (namespace-scoped)

This guide focuses on Method 1 (standalone binary) since it gives you the clearest picture of how Flink’s components fit together, and Method 2 (Docker) as a fast alternative for local testing. If you’re deploying Flink onto an existing Kubernetes cluster, look into the official Flink Kubernetes Operator (currently at 1.15) instead.

Architecture: How Flink Processes Data

Flink separates job coordination from job execution. The JobManager handles scheduling, checkpoint coordination, and resource negotiation, while one or more TaskManagers actually execute the data processing tasks (subtasks) in parallel slots.

                     ┌───────────────────────────────────────────────┐
                     │              Ubuntu 26.04 LTS Host(s)         │
                     │                                               │
                     │   ┌────────────────────────────────────────┐  │
                     │   │              JobManager                │  │
                     │   │  ────────────────────────────────────  │  │
                     │   │  Dispatcher  │ ResourceManager         │  │
                     │   │  JobMaster   │ Checkpoint Coordinator  │  │
                     │   │  Flink Web UI (port 8081)              │  │
                     │   └──────────────────┬─────────────────────┘  │
                     │                      │ schedules tasks        │
                     │        ┌─────────────┼─────────────┐          │
                     │        ▼             ▼             ▼          │
                     │  ┌───────────┐ ┌───────────┐ ┌───────────┐    │
                     │  │TaskManager│ │TaskManager│ │TaskManager│    │
                     │  │  Slot 1   │ │  Slot 1   │ │  Slot 1   │    │
                     │  │  Slot 2   │ │  Slot 2   │ │  Slot 2   │    │
                     │  └───────────┘ └───────────┘ └───────────┘    │
                     │                                               │
                     └───────────────────────────────────────────────┘
                                          │
                                          ▼
                         Sources (Kafka, files, sockets) →
                         Transformations (map, window, join) →
                         Sinks (Kafka, files, databases)

Each TaskManager offers a configurable number of task slots, and Flink’s scheduler distributes parallel subtasks of your job across those slots — this is the core mechanism behind Flink’s horizontal scalability.

Method 1: Standalone Installation from Binary Archive (Recommended)

Step 1 — Download the binary distribution

cd /tmp
wget https://dlcdn.apache.org/flink/flink-2.3.0/flink-2.3.0-bin-scala_2.12.tgz

Step 2 — Verify the download (recommended)

Always verify release artifacts against the published checksum before extracting:

wget https://downloads.apache.org/flink/flink-2.3.0/flink-2.3.0-bin-scala_2.12.tgz.sha512
sha512sum -c flink-2.3.0-bin-scala_2.12.tgz.sha512

Step 3 — Extract and install to `/opt`

sudo mkdir -p /opt/flink
sudo tar -xzf flink-2.3.0-bin-scala_2.12.tgz -C /opt/flink --strip-components=1

Step 4 — Create a dedicated Flink user (recommended for production)

sudo useradd -r -m -d /opt/flink -s /bin/bash flink
sudo chown -R flink:flink /opt/flink

Step 5 — Set environment variables

sudo nano /etc/profile.d/flink.sh

Add the following:

export FLINK_HOME=/opt/flink
export PATH=$FLINK_HOME/bin:$PATH

Apply the changes:

sudo chmod +x /etc/profile.d/flink.sh
source /etc/profile.d/flink.sh

Method 2: Running Flink with Docker

For fast local testing without touching the host filesystem, use the official Flink Docker images with Docker Compose.

Step 1 — Install Docker (if not already installed)

sudo apt update
sudo apt install -y docker.io docker-compose-v2
sudo systemctl enable --now docker

Step 2 — Create a Docker Compose file

mkdir ~/flink-docker && cd ~/flink-docker
nano docker-compose.yml

version: "3.8"
services:
  jobmanager:
    image: flink:2.3.0-scala_2.12-java21
    ports:
      - "8081:8081"
    command: jobmanager
    environment:
      - |
        FLINK_PROPERTIES=
        jobmanager.rpc.address: jobmanager
  taskmanager:
    image: flink:2.3.0-scala_2.12-java21
    depends_on:
      - jobmanager
    command: taskmanager
    scale: 2
    environment:
      - |
        FLINK_PROPERTIES=
        jobmanager.rpc.address: jobmanager
        taskmanager.numberOfTaskSlots: 2

Step 3 — Start the cluster

docker compose up -d

The Flink Web UI will be reachable at http://localhost:8081, identical to the standalone install.

Configuring Flink

Flink’s main configuration file lives at $FLINK_HOME/conf/config.yaml (Flink 2.x moved from the legacy flink-conf.yaml key-value format to a structured YAML file). Key settings to review before starting the cluster:

jobmanager:
  rpc:
    address: localhost
  memory:
    process:
      size: 1600m

taskmanager:
  memory:
    process:
      size: 1728m
  numberOfTaskSlots: 2

parallelism:
  default: 2

Adjust jobmanager.memory.process.size and taskmanager.memory.process.size based on available host RAM, and increase numberOfTaskSlots on TaskManagers with more CPU cores available.

Starting the Cluster

Start the standalone cluster with the bundled script:

$FLINK_HOME/bin/start-cluster.sh

Confirm the JobManager and TaskManager processes are running:

jps

Expected output includes:

12345 StandaloneSessionClusterEntrypoint
12456 TaskManagerRunner

To stop the cluster later:

$FLINK_HOME/bin/stop-cluster.sh

Accessing the Flink Web UI

Open a browser and navigate to:

http://<your-server-ip>:8081

The Web UI shows running and completed jobs, TaskManager metrics, checkpoint history, and lets you cancel or inspect jobs without touching the CLI. If accessing remotely, either open port 8081 in your firewall/security group or tunnel it over SSH:

ssh -L 8081:localhost:8081 user@your-server-ip

Submitting Your First Flink Job

Flink ships with example JARs you can use to validate the cluster end to end.

Step 1 — Run the WordCount batch example

$FLINK_HOME/bin/flink run $FLINK_HOME/examples/batch/WordCount.jar

Step 2 — Run a streaming example

$FLINK_HOME/bin/flink run $FLINK_HOME/examples/streaming/WordCount.jar

Step 3 — Confirm the job in the Web UI

Navigate to http://<your-server-ip>:8081/#/job-manager/jobs — the completed job should appear in the Completed Jobs list with its execution graph and metrics.

Step 4 — Check job output in the logs

tail -f $FLINK_HOME/log/flink-*-taskexecutor-*.out

Setting Up a Multi-Node Standalone Cluster

For a production-style test across multiple Ubuntu 26.04 LTS hosts:

Step 1 — Install Flink identically on every node

Repeat Method 1 on each host, using the same FLINK_HOME path and Flink version everywhere.

Step 2 — Configure `masters` and `workers`

On the JobManager node, edit:

nano $FLINK_HOME/conf/masters

jobmanager-host:8081

nano $FLINK_HOME/conf/workers

taskmanager-host-1
taskmanager-host-2
taskmanager-host-3

Step 3 — Set up passwordless SSH from the JobManager to every TaskManager

ssh-keygen -t ed25519
ssh-copy-id flink@taskmanager-host-1
ssh-copy-id flink@taskmanager-host-2

Step 4 — Start the whole cluster from the JobManager node

$FLINK_HOME/bin/start-cluster.sh

This script SSHes into every host listed in workers and starts a TaskManager process there automatically.

Running Flink as a systemd Service

For a standalone JobManager that survives reboots, create a systemd unit instead of relying on manual script invocation:

sudo nano /etc/systemd/system/flink-jobmanager.service

[Unit]
Description=Apache Flink JobManager
After=network.target

[Service]
Type=forking
User=flink
Group=flink
Environment=FLINK_HOME=/opt/flink
ExecStart=/opt/flink/bin/jobmanager.sh start
ExecStop=/opt/flink/bin/jobmanager.sh stop
Restart=on-failure

[Install]
WantedBy=multi-user.target

Enable and start it:

sudo systemctl daemon-reload
sudo systemctl enable --now flink-jobmanager
sudo systemctl status flink-jobmanager

Repeat the same pattern with a flink-taskmanager.service unit using taskmanager.sh start/stop on each TaskManager host.

Troubleshooting

Symptom	Likely Cause	Fix
`flink: command not found`	`PATH` not updated, or shell not reloaded	Run `source /etc/profile.d/flink.sh`
JobManager fails to start, `Address already in use`	Port 8081 or 6123 already bound by another process	Run `sudo ss -tulpn \| grep -E '8081\|6123'` and stop the conflicting process, or change `rest.port` in `config.yaml`
TaskManager not appearing in Web UI on multi-node cluster	Passwordless SSH not configured, or `workers` file misconfigured	Verify `ssh flink@taskmanager-host` works without a password prompt from the JobManager node
`Insufficient number of network buffers`	TaskManager memory too low for the configured parallelism	Increase `taskmanager.memory.process.size` in `config.yaml`
Job stuck in `CREATED` state indefinitely	No TaskManager slots available	Check `jps` on TaskManager hosts and confirm `numberOfTaskSlots` is sufficient for the job’s parallelism
`UnsupportedClassVersionError` on job submission	Job JAR compiled against a newer/older Java version than the cluster’s JDK	Rebuild the job JAR targeting Java 17 or 21 to match the cluster JDK
Web UI reachable locally but not remotely	Firewall blocking port 8081, or `rest.bind-address` set to `localhost`	Open port 8081 in `ufw`/security group and set `rest.bind-address: 0.0.0.0` in `config.yaml`
Checksum mismatch on manual download	Corrupted download or wrong mirror	Re-download from `downloads.apache.org` directly rather than a third-party mirror

Uninstalling Flink

Standalone binary install:

$FLINK_HOME/bin/stop-cluster.sh
sudo systemctl disable --now flink-jobmanager flink-taskmanager 2>/dev/null
sudo rm -rf /opt/flink
sudo rm /etc/profile.d/flink.sh
sudo userdel -r flink

Docker install:

cd ~/flink-docker
docker compose down -v

FAQ

Does Ubuntu 26.04 LTS include Apache Flink by default?
No. Flink is not part of the base Ubuntu install or its default repositories; it must be downloaded from the official Apache distribution or run via Docker.

Which JDK version does Apache Flink 2.3.0 require?
JDK 17 or JDK 21. Flink 2.x dropped support for Java 8 and Java 11, unlike the Flink 1.x series.

What’s the difference between the standalone cluster and the Kubernetes Operator?
The standalone cluster (covered in this guide) runs directly on VM/bare-metal hosts using shell scripts for process management. The Kubernetes Operator manages Flink JobManagers and TaskManagers as native Kubernetes resources, with built-in support for savepoints, autoscaling, and rolling upgrades — better suited to clusters already running Kubernetes.

Can I run Flink SQL without writing Java or Scala code?
Yes. Flink ships a SQL Client ($FLINK_HOME/bin/sql-client.sh) that lets you run streaming and batch SQL queries interactively against a running cluster.

How do I upgrade to a newer Flink version later?
Stop the cluster, take a savepoint of any running jobs (flink savepoint <job-id>), install the new version alongside the old one, update FLINK_HOME, and resume jobs from the savepoint on the new cluster.
