How to Install Elasticsearch on Ubuntu 26.04 LTS

Elasticsearch remains the backbone of countless search, logging, and observability stacks, and Ubuntu 26.04 LTS (“Resolute Raccoon”) is now a common target for new deployments thanks to its long support window. This guide walks through a clean, production-oriented installation of Elasticsearch on Ubuntu 26.04 using Elastic’s official APT repository, covers the current 8.x vs 9.x decision, and includes hardening, systemd management, and troubleshooting steps you’ll actually need in the field.

Table of Contents

1. Elasticsearch 8.x vs 9.x: Which Should You Install?
2. Prerequisites
3. Architecture Overview
4. Step 1: Update the System and Install Dependencies
5. Step 2: Import the Elastic GPG Key
6. Step 3: Add the Elastic APT Repository
7. Step 4: Install Elasticsearch
8. Step 5: Save the Auto-Generated Security Credentials
9. Step 6: Configure Elasticsearch (elasticsearch.yml)
10. Step 7: Tune the JVM Heap Size
11. Step 8: Start and Enable the Service
12. Step 9: Verify the Installation
13. Step 10: Configure the Firewall (UFW)
14. Optional: Install Kibana
15. Troubleshooting
16. Removing Elasticsearch
17. Related Reading on bckinfo.com

---

Elasticsearch 8.x vs 9.x: Which Should You Install?

Elastic currently maintains two active branches side by side. For a fresh deployment on Ubuntu 26.04, most readers should default to 9.x — but there are legitimate reasons to stay on 8.x.

Criteria	Elasticsearch 9.x	Elasticsearch 8.x
Current version (as of mid-2026)	9.4.1	8.19.15
Best for	New self-managed deployments	Existing 8.x clusters, pinned plugins/clients
Support horizon	Current major branch	Supported through July 15, 2027
APT repository path	https://artifacts.elastic.co/packages/9.x/apt	https://artifacts.elastic.co/packages/8.x/apt
Config format	DEB822 .sources recommended	Legacy .list still works
Java requirement	Bundled OpenJDK	Bundled OpenJDK
Security defaults	TLS + auth enabled out of the box	TLS + auth enabled out of the box

This guide defaults to Elasticsearch 9.x. If you need to stay on 8.x for compatibility reasons, swap 9.x for 8.x in the repository URL in Step 3 — every other step is identical.

Prerequisites

• A server running Ubuntu 26.04 LTS with sudo privileges
• At least 2 GB RAM (4 GB+ recommended for anything beyond testing)
• At least 10 GB free disk space
• A non-root user configured with sudo
• Outbound HTTPS access to artifacts.elastic.co

Architecture Overview

A minimal single-node Elasticsearch deployment on Ubuntu looks like this:

                         ┌─────────────────────────────┐
                         │        Ubuntu 26.04 LTS      │
                         │                              │
  Client / App──HTTPS ──▶│  ┌────────────────────────┐  │
  (port 9200)            │  │   Elasticsearch 9.x     │  │
                         │  │   systemd service        │  │
                         │  │                          │  │
                         │  │  ┌────────────────────┐  │  │
                         │  │  │   JVM (bundled JDK) │  │  │
                         │  │  │   Heap: -Xms/-Xmx   │  │  │
                         │  │  └────────────────────┘  │  │
                         │  │                          │  │
                         │  │  Data:  /var/lib/         │  │
                         │  │         elasticsearch    │  │
                         │  │  Logs:  /var/log/         │  │
                         │  │         elasticsearch    │  │
                         │  │  Config:/etc/             │  │
                         │  │         elasticsearch    │  │
                         │  └────────────────────────┘  │
                         │                              │
                         │   UFW: allow 9200 (scoped)   │
                         └─────────────────────────────┘

For multi-node clusters, replicate this block per node and configure discovery.seed_hosts and cluster.initial_master_nodes accordingly — a topic covered in a dedicated clustering article linked at the end.

Step 1: Update the System and Install Dependencies

sudo apt update && sudo apt upgrade -y
sudo apt install -y apt-transport-https curl gnupg

apt-transport-https ensures APT can pull packages over HTTPS, curl fetches the GPG key, and gnupg handles key verification.

Step 2: Import the Elastic GPG Key

curl -fsSL https://artifacts.elastic.co/GPG-KEY-elasticsearch | \
  sudo gpg --dearmor -o /usr/share/keyrings/elasticsearch-keyring.gpg

This stores Elastic’s signing key in /usr/share/keyrings/ rather than the deprecated global apt-key keyring, which APT on Ubuntu 26.04 no longer supports.

Step 3: Add the Elastic APT Repository

echo "deb [signed-by=/usr/share/keyrings/elasticsearch-keyring.gpg] https://artifacts.elastic.co/packages/9.x/apt stable main" | \
  sudo tee /etc/apt/sources.list.d/elastic-9.x.list

Refresh the package index:

sudo apt update

If you specifically need the 8.x branch, replace 9.x with 8.x in both the URL and the filename above.

Step 4: Install Elasticsearch

sudo apt install elasticsearch -y

Elasticsearch ships with a bundled OpenJDK build, so there’s no separate Java installation step required. The package installer performs a security autoconfiguration pass automatically — TLS for the HTTP and transport layers is enabled, and authentication is turned on by default.

Step 5: Save the Auto-Generated Security Credentials

During installation, watch the terminal output for a block similar to:

--------------------------- Security autoconfiguration information ------------------------------

Authentication and authorization are enabled.
TLS for the transport and HTTP layers is enabled and configured.

The generated password for the elastic built-in superuser is: <your-generated-password>

The generated enrollment token for Kibana instances: <your-enrollment-token>
----------------------------------------------------------------------------------------------------

Copy both values immediately — they scroll past quickly and are not stored in plain text anywhere else by default. If you miss them, you can reset the elastic user’s password later:

sudo /usr/share/elasticsearch/bin/elasticsearch-reset-password -u elastic

Step 6: Configure Elasticsearch (elasticsearch.yml)

Open the main configuration file:

sudo nano /etc/elasticsearch/elasticsearch.yml

For a single-node development or small production instance, set:

cluster.name: bckinfo-es-cluster
node.name: node-1
network.host: 0.0.0.0
discovery.type: single-node

network.host: 0.0.0.0 binds Elasticsearch to all interfaces — fine behind a firewall or private network, but pair it with UFW rules (Step 10) or a reverse proxy before exposing the server publicly. For a strictly local instance, use network.host: localhost instead.

Step 7: Tune the JVM Heap Size

Elasticsearch’s default heap sizing is conservative. Edit the JVM options:

sudo nano /etc/elasticsearch/jvm.options.d/heap.options

Add explicit -Xms and -Xmx values set to the same size, at roughly 50% of available system RAM, and never exceeding ~31 GB (to stay under the compressed-pointers threshold):

-Xms2g
-Xmx2g

Save and exit. This file is picked up automatically on the next service start.

Step 8: Start and Enable the Service

sudo systemctl daemon-reload
sudo systemctl enable --now elasticsearch

Check the service state:

sudo systemctl status elasticsearch

You should see active (running).

Step 9: Verify the Installation

Query the local HTTPS endpoint using the elastic superuser credentials saved in Step 5:

curl --cacert /etc/elasticsearch/certs/http_ca.crt \
  -u elastic:<your-generated-password> \
  https://localhost:9200

A healthy response looks like:

{
  "name" : "node-1",
  "cluster_name" : "bckinfo-es-cluster",
  "version" : {
    "number" : "9.4.1",
    "build_flavor" : "default"
  },
  "tagline" : "You Know, for Search"
}

You can also confirm the installed package and binary version directly:

apt-cache policy elasticsearch
sudo /usr/share/elasticsearch/bin/elasticsearch --version

Step 10: Configure the Firewall (UFW)

If Elasticsearch only needs to be reachable from specific hosts (an application server, a Kibana instance, or a monitoring tool), scope the rule instead of opening 9200 to the world:

sudo ufw allow from <trusted-ip> to any port 9200 proto tcp
sudo ufw enable
sudo ufw status

For a fully local, single-machine setup, skip this step entirely and keep network.host: localhost.

Optional: Install Kibana

Kibana uses the same APT repository and GPG key you already configured:

sudo apt install kibana -y
sudo systemctl enable --now kibana

Retrieve a Kibana enrollment token if you didn’t save the one shown during the Elasticsearch install:

sudo /usr/share/elasticsearch/bin/elasticsearch-create-enrollment-token -s kibana

Then open http://<server-ip>:5601 in a browser and paste the token to complete setup.

Troubleshooting

Symptom	Likely Cause	Fix
systemctl status elasticsearch shows failed	Insufficient memory or heap misconfiguration	Check journalctl -u elasticsearch --no-pager | tail -50; lower -Xms/-Xmx in heap.options
max virtual memory areas vm.max_map_count [65530] is too low	Kernel vm.max_map_count below required threshold	Run sudo sysctl -w vm.max_map_count=262144 and persist it in /etc/sysctl.conf
curl: (60) SSL certificate problem	Missing or wrong CA cert path	Point --cacert to /etc/elasticsearch/certs/http_ca.crt
401 Unauthorized on API calls	Wrong or lost elastic password	Run elasticsearch-reset-password -u elastic
Service starts but port 9200 unreachable remotely	network.host still set to localhost, or UFW blocking the port	Update elasticsearch.yml and add the appropriate UFW rule
apt update fails to fetch the Elastic repo	GPG key not linked correctly in the .list file	Re-verify the signed-by path matches the keyring file exactly
High memory pressure / OOM kills	Heap set too close to total system RAM	Keep heap at ~50% of RAM, leaving room for the OS file cache

Removing Elasticsearch

To fully remove Elasticsearch and its data:

sudo systemctl stop elasticsearch
sudo apt purge elasticsearch -y
sudo rm -rf /var/lib/elasticsearch /var/log/elasticsearch /etc/elasticsearch
sudo apt autoremove -y
