How to Install Apache Spark on Ubuntu 26.04 LTS (Standalone & Cluster Mode)

Apache Spark remains one of the most widely used distributed data processing engines for batch analytics, streaming, and machine learning workloads. This guide walks through a complete, production-oriented installation of Apache Spark 3.5 on Ubuntu 26.04 LTS, covering single-node standalone setup, multi-node cluster configuration, systemd service management, PySpark, and common troubleshooting scenarios.

Table of Contents

1. What Is Apache Spark
2. Prerequisites
3. Spark Architecture Overview
4. Deployment Mode Comparison
5. Step 1: Update System and Install Java
6. Step 2: Create a Dedicated Spark User
7. Step 3: Download and Install Apache Spark
8. Step 4: Configure Environment Variables
9. Step 5: Verify the Installation
10. Step 6: Configure Standalone Cluster Mode
11. Step 7: Run Spark Master and Worker as systemd Services
12. Step 8: Configure the Firewall (UFW)
13. Step 9: Submit a Sample Job
14. Step 10: Set Up PySpark
15. Spark vs Hadoop MapReduce vs Flink
16. Performance Tuning Notes
17. Troubleshooting
18. FAQ
19. Conclusion
20. Related Articles

What Is Apache Spark

Apache Spark is an open-source, in-memory distributed computing engine designed for large-scale data processing. Compared to traditional disk-based MapReduce, Spark keeps intermediate data in memory across a Directed Acyclic Graph (DAG) of transformations, which typically yields significantly faster iterative workloads such as machine learning training, graph processing, and interactive SQL analytics. Spark ships with four core libraries: Spark SQL, Spark Streaming (Structured Streaming), MLlib, and GraphX, all built on top of the same core execution engine.

Prerequisites

Requirement	Minimum Spec	Recommended
OS	Ubuntu 26.04 LTS (server or desktop)	Ubuntu 26.04 LTS, updated
CPU	2 vCPU	4+ vCPU per node
RAM	4 GB	16 GB+ per worker node
Disk	20 GB free	SSD, 50 GB+
Java	OpenJDK 17	OpenJDK 17 (LTS)
Network	Static IP recommended for cluster nodes	Static IP + DNS resolution
Access	sudo/root privileges	sudo/root privileges

Scala and Python are optional depending on which API you plan to use — Spark bundles a Scala runtime, and PySpark installs via pip separately (covered in Step 10).

Spark Architecture Overview

                        +-----------------------------+
                        |      Client / Driver        |
                        |(SparkContext / SparkSession)|
                        +--------------+--------------+
                                       |
                                       | submits job / DAG
                                       v
                        +-----------------------------+
                        |      Cluster Manager        |
                        |  (Standalone / YARN / K8s)  |
                        +--------------+--------------+
                                       |
                 +---------------------+---------------------+
                 |                     |                     |
                 v                     v                     v
        +----------------+   +----------------+      +----------------+
        |  Worker Node 1 |   |   Worker Node 2 |     |   Worker Node N |
        | +-----------+  |   |  +-----------+  |     |  +-----------+  |
        | | Executor  |  |   |  | Executor  |  |     |  | Executor  |  |
        | | (Tasks)   |  |   |  | (Tasks)   |  |     |  | (Tasks)   |  |
        | +-----------+  |   |  +-----------+  |     |  +-----------+  |
        +----------------+   +----------------+      +----------------+

The Driver builds the execution DAG and requests resources from the Cluster Manager. Each Worker Node runs one or more Executors, which execute tasks and cache data in memory for the duration of the application.

Deployment Mode Comparison

Mode	Best For	Resource Manager	Setup Complexity
Local	Development, testing, single-machine jobs	None (in-process)	Very low
Standalone	Small-to-medium dedicated clusters	Spark’s built-in manager	Low
YARN	Existing Hadoop ecosystem	Hadoop YARN	Medium
Kubernetes	Cloud-native, elastic, containerized workloads	Kubernetes API	Medium-High

This guide focuses on Local mode for quick verification and Standalone cluster mode for a self-managed production deployment, since it does not require an existing Hadoop or Kubernetes stack.

Step 1: Update System and Install Java

Spark 3.5 runs on OpenJDK 17.

sudo apt update && sudo apt upgrade -y
sudo apt install -y openjdk-17-jdk wget curl

java -version

Expected output should show openjdk version "17...".

Step 2: Create a Dedicated Spark User

Running Spark under a dedicated system user isolates its processes and file permissions from other services.

sudo adduser --system --group --home /opt/spark spark
sudo mkdir -p /opt/spark
sudo chown -R spark:spark /opt/spark

Step 3: Download and Install Apache Spark

Always verify the current release on the official Apache Spark downloads page before running this step, since version numbers change.

cd /tmp
wget https://downloads.apache.org/spark/spark-3.5.3/spark-3.5.3-bin-hadoop3.tgz

tar -xzf spark-3.5.3-bin-hadoop3.tgz
sudo mv spark-3.5.3-bin-hadoop3 /opt/spark/spark-3.5.3
sudo ln -s /opt/spark/spark-3.5.3 /opt/spark/current
sudo chown -R spark:spark /opt/spark

The symlink /opt/spark/current makes future version upgrades a one-line change instead of a full reconfiguration.

Step 4: Configure Environment Variables

sudo tee /etc/profile.d/spark.sh <<'EOF'
export SPARK_HOME=/opt/spark/current
export PATH=$PATH:$SPARK_HOME/bin:$SPARK_HOME/sbin
export JAVA_HOME=/usr/lib/jvm/java-17-openjdk-amd64
EOF

sudo chmod +x /etc/profile.d/spark.sh
source /etc/profile.d/spark.sh

Confirm JAVA_HOME matches your actual installation path with update-alternatives --list java if it differs.

Step 5: Verify the Installation

spark-shell --version

You should see the Spark version banner along with the Scala and Java versions it was built against. Exit with :quit or Ctrl+D.

Quick local-mode smoke test:

run-example SparkPi 100

This calculates an approximation of Pi using 100 partitions and confirms the local execution engine works end-to-end.

Step 6: Configure Standalone Cluster Mode

On the master node, define which hosts act as workers:

sudo -u spark cp $SPARK_HOME/conf/workers.template $SPARK_HOME/conf/workers
sudo -u spark nano $SPARK_HOME/conf/workers

Add one worker hostname or IP per line, for example:

worker1.internal
worker2.internal
worker3.internal

Create spark-env.sh on all nodes:

sudo -u spark cp $SPARK_HOME/conf/spark-env.sh.template $SPARK_HOME/conf/spark-env.sh

Append the following:

export SPARK_MASTER_HOST=master.internal
export SPARK_WORKER_CORES=4
export SPARK_WORKER_MEMORY=8g
export SPARK_MASTER_PORT=7077
export SPARK_MASTER_WEBUI_PORT=8080

Adjust SPARK_WORKER_CORES and SPARK_WORKER_MEMORY based on each node’s actual capacity, leaving headroom for the OS.

Ensure passwordless SSH from the master to each worker (required only if you plan to use start-all.sh for orchestration; the systemd approach in Step 7 avoids this dependency):

sudo -u spark ssh-keygen -t ed25519 -N ""
sudo -u spark ssh-copy-id spark@worker1.internal

Step 7: Run Spark Master and Worker as systemd Services

Managing Spark via systemd is more reliable in production than the bundled shell scripts, since it gives you automatic restarts and standard logging.

Master service (/etc/systemd/system/spark-master.service):

[Unit]
Description=Apache Spark Master
After=network.target

[Service]
Type=forking
User=spark
Group=spark
Environment="JAVA_HOME=/usr/lib/jvm/java-17-openjdk-amd64"
Environment="SPARK_HOME=/opt/spark/current"
ExecStart=/opt/spark/current/sbin/start-master.sh
ExecStop=/opt/spark/current/sbin/stop-master.sh
Restart=on-failure

[Install]
WantedBy=multi-user.target

Worker service (/etc/systemd/system/spark-worker.service), deployed on each worker node:

[Unit]
Description=Apache Spark Worker
After=network.target

[Service]
Type=forking
User=spark
Group=spark
Environment="JAVA_HOME=/usr/lib/jvm/java-17-openjdk-amd64"
Environment="SPARK_HOME=/opt/spark/current"
ExecStart=/opt/spark/current/sbin/start-worker.sh spark://master.internal:7077
ExecStop=/opt/spark/current/sbin/stop-worker.sh
Restart=on-failure

[Install]
WantedBy=multi-user.target

Enable and start:

sudo systemctl daemon-reload
sudo systemctl enable --now spark-master.service   # on master
sudo systemctl enable --now spark-worker.service    # on each worker

Check the cluster web UI at http://master.internal:8080 to confirm registered workers.

Step 8: Configure the Firewall (UFW)

sudo ufw allow 7077/tcp    # Master RPC
sudo ufw allow 8080/tcp    # Master web UI
sudo ufw allow 8081/tcp    # Worker web UI
sudo ufw allow 4040/tcp    # Application/job UI
sudo ufw reload

Restrict these ports to your internal subnet in production, e.g. sudo ufw allow from 10.0.0.0/24 to any port 7077.

Step 9: Submit a Sample Job

spark-submit \
  --master spark://master.internal:7077 \
  --deploy-mode client \
  --executor-memory 4g \
  --total-executor-cores 8 \
  $SPARK_HOME/examples/src/main/python/pi.py 1000

Track job progress via the application UI at http://<driver-host>:4040 while it runs.

Step 10: Set Up PySpark

sudo apt install -y python3-pip python3-venv
python3 -m venv ~/pyspark-env
source ~/pyspark-env/bin/activate
pip install pyspark==3.5.3

Test with a minimal script:

from pyspark.sql import SparkSession

spark = SparkSession.builder \
    .appName("SparkOnUbuntu2604") \
    .master("spark://master.internal:7077") \
    .getOrCreate()

df = spark.range(1000000).toDF("id")
print(df.count())

spark.stop()

python3 pyspark_test.py

Spark vs Hadoop MapReduce vs Flink

Feature	Apache Spark	Hadoop MapReduce	Apache Flink
Processing model	In-memory, DAG-based	Disk-based, two-stage	True streaming, in-memory
Latency	Low (batch/micro-batch)	High	Very low (native streaming)
Best fit	Batch + iterative ML	Legacy batch ETL	Real-time event processing
Fault tolerance	RDD lineage recomputation	Task re-execution	Distributed snapshots (checkpointing)
Ecosystem	Spark SQL, MLlib, GraphX	Hive, Pig	Flink SQL, Table API, CEP

For a deeper hands-on comparison on the streaming side, see the companion Apache Flink installation guide linked below.

Performance Tuning Notes

• Set spark.executor.memory and spark.executor.cores explicitly rather than relying on defaults; unset values often under-utilize larger nodes.
• Enable spark.sql.shuffle.partitions tuning for Spark SQL workloads — the default of 200 partitions is rarely optimal for small or very large datasets.
• Use spark.serializer=org.apache.spark.serializer.KryoSerializer for better serialization throughput on RDD-heavy jobs.
• Monitor GC pauses via the executor logs; excessive full GCs usually indicate under-provisioned executor memory relative to cached data size.

Troubleshooting

Symptom	Likely Cause	Fix
JAVA_HOME is not set on startup	Environment variable not exported for the spark user’s shell	Confirm /etc/profile.d/spark.sh is sourced; set JAVA_HOME directly in spark-env.sh
Worker not appearing in Master UI	Firewall blocking port 7077, or wrong SPARK_MASTER_HOST	Check ufw status, verify DNS/hosts resolution between nodes
Address already in use on master start	Previous Spark process not fully stopped	sudo systemctl stop spark-master, then check ps aux | grep spark, kill stray PID
Job stuck in ACCEPTED state indefinitely	Insufficient cluster resources for requested executors	Lower --executor-memory / --total-executor-cores, or add worker capacity
Permission denied writing logs	Spark directories not owned by the spark user	sudo chown -R spark:spark /opt/spark
PySpark ModuleNotFoundError: pyspark	Virtual environment not activated, or version mismatch with cluster	Activate venv, ensure PyPI pyspark version matches cluster’s Spark version
Slow shuffle stages	Too many/few shuffle partitions, disk-bound shuffle	Tune spark.sql.shuffle.partitions, use SSD-backed spark.local.dir

FAQ

Does Apache Spark require Hadoop to run on Ubuntu 26.04?
No. The hadoop3 prebuilt binary bundles the Hadoop client libraries needed to talk to HDFS or S3-compatible storage, but a full standalone Spark cluster with local or NFS-backed storage does not need a running Hadoop cluster.

Can Spark run in standalone mode alongside Docker containers already on the host?
Yes, as long as the configured ports (7077, 8080, 8081, 4040) don’t conflict with existing container port mappings. Running Spark itself inside containers is also supported via the official Spark Docker images.

How do I upgrade Spark without breaking existing configs?
Download the new version to a separate directory under /opt/spark/, then repoint the /opt/spark/current symlink after copying over your spark-env.sh and workers files.

Is Java 17 mandatory, or can I use Java 11?
Spark 3.5 supports both Java 8 (deprecated), 11, and 17. Java 17 is recommended for Ubuntu 26.04 since it’s the LTS version shipped in the default repositories.

Conclusion

Apache Spark on Ubuntu 26.04 LTS can be deployed as a lightweight local instance for development or scaled into a multi-node standalone cluster managed by systemd for production batch and ML workloads. The setup shown here — dedicated system user, symlinked versioned installs, systemd-managed master/worker services, and UFW-restricted ports — gives a maintainable baseline that’s straightforward to extend toward YARN or Kubernetes-based deployments as workload requirements grow.
